Products
LF12040-120H-B1.2
Main Application
Car/Van/Truck
Capacity
40 Ah
Nominal Voltage
12,8 V
CCA
900 A
Weight
5,3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
120/70 A
Remarks
For cars with AGM equalization charging mode[1]
[1]- Cars with starter <=1.6kw
[2]- Raised charger cut off, at 15.3V
[3]- Improved CCA
LF12040-120X-B1.2
Main Application
Car/Van/Truck
Capacity
40 Ah
Nominal Voltage
12,8 V
CCA
900 A
Weight
5,3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
120/70 A
Remarks
For cars with super-capacitor or/and hybrid system[1]
[1]- Cars with starter <=1.6kw
[2]- Raised charger cut off, at 15.3V
[3]- Buffered overload protection
[4]- Improved CCA
LF12040-300E-B1.2
Main Application
Car/Van/Truck, Marine
Capacity
40 Ah
Nominal Voltage
12,8 V
CCA
950 A
Weight
5,3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
240/200 A
Remarks
Mostly for Diesel engines and high CC petrol engines[1]
[1]- For cars with starter <=2.8kw
LF12040-300X-B1.2
Main Application
Car/Van/Truck, Marine
Capacity
40 Ah
Nominal Voltage
12,8 V
CCA
1000 A
Weight
5,3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
240/200 A
Remarks
For cars with super-capacitor or/and hybrid systems[1]
[1]- Cars with starter <=2.8kw
[2]- Raised charger cut off, at 15.3V
[3]- Buffered overload protection
[4]- Improved CCA
LF12040-B5X2
Main Application
Car/Van/Truck
Capacity
40 Ah
Nominal Voltage
12,8 V
CCA
1100 A
Weight
5,3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
300/300 A
Remarks
For cars with super-capacitor or/and hybrid systems[1]
[1]- Cars with starter <=3kw
[2]- Low voltage protection,5A active cells balancer use
[3]- As starter battery, for vehicles with BMS, Mercedes, and BMW models [4]- Double balancing power
[2]- Low voltage protection,5A active cells balancer use
[3]- As starter battery, for vehicles with BMS, Mercedes, and BMW models [4]- Double balancing power
LF12100-120E-B1.2
Main Application
Marine
Capacity
100 Ah
Nominal Voltage
12,8 V
CCA
900 A
Weight
11 Kg
Dimension (HLW)
265x184x148 mm
Discharging/Charging
120/70 A
LF12100-300E-B1.2
Main Application
Marine
Capacity
100 Ah
Nominal Voltage
12,8 V
CCA
1000 A
Weight
11 Kg
Dimension (HLW)
265x184x148 mm
Discharging/Charging
240/200 A
