E-Box Assembly Battery Products

LF12050-120-B5
50AH [120]
Main Application
EV Car / Auxiliary Battery
Capacity
50 AH
Nominal Voltage
12.8 V
CCA
1000 A
Weight
5.3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
120/70 A
Remarks
For cars with super-capacitor or/and hybrid system[1]
[1] Cars with starter <=1.6 kW
[2] Buffered overload protection
[3] Short-Circuit Protection
[4] Improved CCA
Recommended for gasoline engines below 1.6 litres, EV Cars and auxiliary batteries
LF12B50-120-B5
50AH [120]
Main Application
EV Car / Auxiliary Battery
Capacity
50 AH
Nominal Voltage
12.8 V
CCA
1000 A
Weight
6.2 Kg
Dimension (HLW)
175.74x242.31x162.8 mm
Discharging/Charging
120/70 A
Remarks
For cars with super-capacitor or/and hybrid systems[1]
[1] Cars with starter <=1.6 kW
[2] Buffered overload protection
[3] Short-Circuit Protection
[4] Improved CCA
Enlarge size recommended for gasoline engines below 1.6 litres, EV Cars and auxiliary batteries
LF12050-240-B5
50AH [240]
Main Application
Car / Van / Truck / Marine
Capacity
50 AH
Nominal Voltage
12.8 V
CCA
1300 A
Weight
5.3 Kg
Dimension (HLW)
175x162x128 mm
Discharging/Charging
240/200 A
Remarks
For cars with super-capacitor or/and hybrid systems[1]
[1] Cars with starter <=2.8 kW
[2] Buffered overload protection
[3] Short-Circuit Protection
[4] Improved CCA
Recommended for large Gasoline Engine and all Diesel Engine
LF12B50-240-B5
50AH [240]
Main Application
Car / Van / Truck
Capacity
50 AH
Nominal Voltage
12.8 V
CCA
1300 A
Weight
6.2 Kg
Dimension (HLW)
175.74x242.31x162.8 mm
Discharging/Charging
240/200 A
Remarks
For cars with super-capacitor or/and hybrid systems[1]
[1] Cars with starter <=2.8 kW
[2] Buffered overload protection
[3] Short-Circuit Protection
[4] Improved CCA
Enlarge size Recommended for large Gasoline Engine and all Diesel Engine
LF12100-240-B5
100AH [460]
Main Application
Car / Van / Truck
Capacity
100 AH
Nominal Voltage
12.8 V
CCA
1900 A
Weight
11.3 Kg
Dimension (HLW)
175.74x242.31x162.8 mm
Discharging/Charging
240/200 A
Remarks
For cars with AGM equalization charging mode[1]
[1] Cars with starter <=4.5 kW
[2] Super Higher Power model
[3] Improved CCA
[4] Buffered overload protection
Recommended use for All Vehicles with large engines, Truck, Marine industrial application
LF12105-120E
105AH [120]
Main Application
Storage / Traction Battery
Capacity
105 Ah
Nominal Voltage
12.8 V
CCA
900 A
Weight
11 Kg
Dimension (HLW)
245x184x148 mm
Discharging/Charging
120/70 A
[1] Energy Storage for House / Office UPS
[2] Energy Storage for Boats
[3] Traction Batteries for Buggies / Scooters one-to-one Lead-Acid
replacement with no modification required for vehicles
LF1250YT5-50X
5AH
Main Application
Motorcycle
Capacity
5 Ah
Nominal Voltage
12.8 V
CCA
150
Weight
0.9 KG
Dimension (HLW)
111x69x106 mm
Discharging/Charging
50/50 A
Universal application: This model is designed for an engine starting battery; however, the TSAPA Energy Box can also be used as an energy storage unit. Lightweight lithium battery only.
Compatible with: YTZ6V | YTZ8V | YTZ7V.
LF1250YT5-100X
6AH
Main Application
Motorcycle
Capacity
6 Ah
Nominal Voltage
12.8 V
CCA
300
Weight
0.9 KG
Dimension (HLW)
111x69x106 mm
Discharging/Charging
100/100 A
Universal application: This model is designed for an engine starting battery; however, the TSAPA Energy Box can also be used as an energy storage unit. Lightweight lithium battery only.
Compatible with: YTZ6V | YTZ8V | YTZ7V.
